Success story

M-Fly. The University of Michigan Team at SAE Aero Design Competition

m fly
  • Institution: M-Fly team - University of Michigan
  • ESTECO Software Solution: modeFRONTIER
  • Benefits:
    Explore a much larger design space in significantly less time
    Design of Experiments (DOE) runs give us more data that they have ever gotten in our past design cycles in terms of different configurations
    Save precious time and improve their design

Long, freezing winters in Michigan leave the M-Fly team with only a month and a half to design and test their plane for the SAE Competition. Thanks to modeFRONTIER, the team can save precious time and improve their design.

The SAE Aero Design Competition was created to connect engineering students with real-life engineering experiences and prepare them for their professional paths. As of this year, the M-Fly team participates both in the regular and the advanced class of the Competition. The 2016/2017 regular class objective is to maximize the amount of “passengers” on the plane without leaving empty seats - a realistic challenge faced by commercial airliners. The advanced class includes the design of the internal combustion power, static and dynamic payloads that must be dropped on a target during the flight, as well as the use of sensors and other electronic systems. M-Fly has partnered with ESTECO Academy and will benefit from free training and access to modeFRONTIER optimization platform to improve their aircraft design and validate analysis results faster.

Download success story

"modeFRONTIER allows us to explore a much larger design space in significantly less time than we could do by ourselves."

Beldon Lin M-Fly team member University of Michigan

At M-Fly, our goal is to teach aerospace engineering, specifically aircraft design through competing at the SAE Aero Design competition. We balance winning and teaching, so we try to involve as many interested University of Michigan students in our project, while still designing the best aircraft for the competition. However, our design cycle is brutal as we have two major factors against us: our school year and the weather. If we want to finish the testing phase before we head to competition, we need to get to the final design by Thanksgiving and finish the construction in January: a very tight schedule. In Michigan, from December through March the temperature highs are hovering at freezing temperatures and opportunities for prime weather conditions to flight test are minimal. If we get lucky, we can perform a flight test or two before we head off to competition which is in the much nicer Southern United States (the competition rotates between Florida, Georgia, and Texas). The more time we have with a full aircraft built, the bigger are the chances of us getting more test flights in. That is where modeFRONTIER comes into play - it allows us to explore a much larger design space in significantly less time than we could do by ourselves. Just the Design of Experiments (DOE) runs give us more data that we have ever gotten in our past design cycles in terms of different configurations. We are currently using modeFRONTIER to do two things: iterate through many different configurations to optimize and do multi-disciplinary analysis since it interfaces so well with other analysis and CAD software we have here at Michigan such as ANSYS, StarCCM+, and SolidWorks. Instead of a standard design, analyze, build, test, go back to first step and repeat - design cycle, we can multiply the iterations for each step: design x 10000 -> analyze x 10000 -> downselect design -> build -> test and repeat the last 3 steps, with the first 3 steps taking only a couple of hours if needed. modeFRONTIER also has a superb post processing capability that allows us to analyze our results in many different ways to make sure we are choosing the right design, as well as provide insights into our design problem.

AdvLeadsPhoto Comp
ESTECO ACADEMY logo Color
M-Fly team - University of Michigan

M-Fly is a Society of Automotive Engineers (SAE) Aerospace Design team at the University of Michigan. It is dedicated to promoting opportunities for students to practice applying their knowledge to aerospace projects outside the classroom. Students of all majors and standing are welcome to join the team. M-Fly competes in the Regular Class SAE Aero Design Competition annually and in the Advanced Class since 2016. The competition is based on three judged portions: a written design report, an oral presentation, and a flying stage. umich.edu/~mfly
